| Wireless |
| Standard |
IEEE802.11 ax/ac/n/g/b/a |
| MIMO |
MU-MIMO |
| Wireless speed |
2.4 GHz: 575 Mbps |
| 5 GHz: 00 Mbps |
| Frequency band |
2.4 GHz: |
| USA (FCC): 2.412 to 2.462 GHz |
| Europe (ETSI): 2.412 to 2.472 GHz |
| 5 GHz: |
| USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHz |
| European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz |
| Bandwidth |
20-, 40- ,80- and 160-MHz |
| Conducted typical transmit output power*1 |
US (2.4 GHz/5 GHz): |
| 23/25 dBm |
| EU (2.4 GHz/5 GHz): |
| 19/22 dBm |
| RF Design |
| Antenna type |
4x4 + 2x2 MIMO Embedded Antenna |
| Antenna gain |
2.4 GHz: |
| Peak Gain 5dBi |
| 5 GHz: |
| Peak Gain 6dBi |
| Minimum receive sensitivity |
Min. Rx sensitivity up to -101 dBm |
| WLAN Feature |
| Band steering |
Yes |
| WDS/Mesh*2 |
Yes (V6.10) |
| Fast roaming |
Pre-authentication, PMK caching and 802.11r/k/v |
| DCS |
Yes |
| Load balancing |
Yes |
| Advanced cellular coexistence |
Yes |
| Security |
| Encryption |
WEP |
| WPA |
| WPA2 |
| WPA3 |
| Authentication |
IEEE 802.1X |
| |
RADIUS authentication |
| Access management |
L2-isolation |
| |
MAC filtering |
| |
Rogue AP detection |
| Networking |
| IPv6 |
Yes |
| VLANs |
Yes |
| WMM |
Yes |
| U-APSD |
Yes |
| Management |
| Operating mode |
Cloud managed |
| Standalone |
| ZON Utility |
Discovery of Zyxel switches, APs and gateways |
| Centralized and batch configurations: |
| IP configuration |
| IP renew |
| Device reboot |
| Device locating |
| Web GUI access |
| Firmware upgrade |
| Password configuration |
| Zyxel Wireless Optimizer |
WiFi AP planning |
| Web UI/CLI |
Yes |
| SNMP |
Yes |
| Physical Specifications |
| Item |
Dimensions (WxDxH)(mm/in.) |
| 180 x 180 x 39/7.09 x 7.09 x 1.54 |
| Weight (g/lb.) |
| 453/1 |
| Packing |
Dimensions (WxDxH)(mm/in.) |
| 229 x 216 x 64/9.02 x 8.5 x 2.52 |
| Weight (g/lb.) |
| 1065/2.36 |
| Included accessories |
Power adapter |
| Mount plate |
| Mounting screws |
| MTBF (hr) |
329,004 |
| Physical Interfaces |
| Ethernet port |
2 x 1/2.5Gbps LAN
2 x 1Gbps LAN
|
| Power |
PoE (802.3)at: power draw 19 W |
| DC input : 12 VDC 2A |
| PoE modes |
IEEE 802.3af: 2.4GHz 1T2R; 5GHz 2T4R |
| IEEE 802.3at: Unrestricted |
| IEEE 802.3bt: Unrestricted |
| Environmental Specifications |
| Operating |
Temperature |
| 0°C to 50°C/32°F to 122°F |
| Humidity |
| 10% to 95% (non-condensing) |
| Storage |
Temperature |
| -40°C to 70°C/-40°F to 158°F |
| Humidity |
| 10% to 90% (non-condensing) |
| Certifications |
Radio |
| FCC Part 15C |
| FCC Part 15E |
| ETSI EN 300 328 |
| EN 301 893, LP0002 |
| EMC |
FCC Part 15B |
| EN 301 489-2 |
| EN 301 489-18 |
| EN55022 |
| EN55024 |
| EN61000-3-2/-4 |
| EN60601-1-3 |
| BSMI CNS13439 |
| Safety |
Safety EN 60950-2 |
| IEC 60950-2 |
| BSMI CNS14336-2 |
